For this type of fiber optic cable, the loose tubes are stranded around a strength member, wraped by aluminum-plastic laminated tape and the cable is completed with an outer PE sheath.
This fiber optic cable is in good main pferfamcance suchas low loss and sipersion. The longitudinal wrap of aluminum tape enhances cable’s moisture proof performance and ensures cable’s flexibility and anti-bending capability.In this fiber optic cable, water-blocking cable gel is fully filled outside the strength member and inside the cable core, which ensures the cable’s moisture proof and water barrier performance.
·Fiber count :2~288 , low loss, low dispersion.
·Proper design and precise excess length control offer
excellent mechanical and environmental properties to
cable.
·Water-blocking cable gel is fully filled outside the
strength member and inside the cable core, which ensures the
cable’s moisture proof and water barrier performance.
·The longitudinal wrap of aluminum tape enhances cable’s
moisture proof performance and ensures cable’s flexibility
and anti-bending capability.
·Applicable to long distance, inter-exchange communication,
CATV, computer network transmission system, etc.
·Jacket can be made of LSZH material,(The model turns to
GYTZA in the case)
Items | Test Standard | Specified Value | Requirements |
Tension | IEC 60794-1-2-E1 | See Technical Data |
Additional attenuation: ≤0.1dB after test |
Crush | IEC 60794-1-2-E3 | See Technical Data |
Additional attenuation: ≤0.1dB after test |
Impact | IEC 60794-1-2-E4 |
R=300mm, 10Nm, one in 3 different places |
Additional attenuation: ≤0.1dB after test |
Repeated Bending | IEC 60794-1-2-E6 | R=20*D |
Additional attenuation: ≤0.1dB after test |
Water Penetration | IEC 60794-1-2-F5 |
Sample length=3m, Water height=1m, 24 hours |
No water leakage |
Temperature Cycling | IEC 60794-1-2-F1 | ‘-40℃- +70℃ |
Attenuation change: ≤0.05dB/kM after test |
G.652.D | G.655 | 50/125μm | 62.5/125μm | ||
Attenuation | @850nm | ≤3.0 dB/km | ≤3.0 dB/km | ||
@1300nm | ≤1.0 dB/km | ≤1.0 dB/km | |||
@1310nm | ≤0.36 dB/km | ≤0.40 dB/km | |||
@1550nm | ≤0.22 dB/km | ≤0.23 dB/km | |||
Bandwith | @850nm | ≥500 MHz*km | ≥200 MHz*km | ||
@1300nm | ≥1000 MHz*km | ≥600 MHz*km | |||
Polarization mode dispersion |
Individual fibre | ≤0.20 ps/√km | ≤0.20 ps/√km | ||
Design link value (M=20, Q=0.01%) | ≤0.1 ps/√km | ≤0.1 ps/√km |
Fiber count | Cable core units | Max. fiber No. in losse tube | Cable diameter(mm) | Cable weight(kg/km) | Tensile Strength(long/short term-N) | Crush resistance (long/short term) (N/100mm) |
2-30 | 5 | 6 | 9.2 | 85 | 600/1500 | 300/1000 |
32-36 | 6 | 6 | 10.2 | 107 | 600/1500 | 300/1000 |
38-60 | 5 | 12 | 10.4 | 110 | 600/1500 | 300/1000 |
62-72 | 6 | 12 | 11.4 | 130 | 600/1500 | 300/1000 |
74-96 | 8 | 12 | 13.6 | 165 | 600/1500 | 300/1000 |
98-120 | 10 | 12 | 14.8 | 195 | 600/2000 | 300/1000 |
122-144 | 12 | 12 | 16.4 | 236 | 600/2500 | 300/1000 |
146-216 | 18 | 12 | 16.4 | 232 | 600/2500 | 300/1000 |
218-288 | 24 | 12 | 20.0 | 300 | 600/3000 | 300/1000 |
