Pcb Manufacturing Amplifier Main Board

We have a professional R&D team for developing printed circuit board (PCB) and embedded firmware. It is the first process to connect smart device. We have years of experience in IoT hardware and firmware design.

• Electronic PCB Manufacturing Services

Electronic contract manufacturing services are the ones that we use for outsourcing our production load. These sorts of companies offer a wide range of services relating to designing, building, distributing, and repairing of electronic parts. Most renowned electronic tycoons today rely on contract electronic manufacturing. However, some industrialists have gone so far as to lease out all of their operations to electronic contract manufacturing companies. Some of the services provided by these companies include but are not limited to:

• Prototyping
• PCB assembly
• Electromechanical assembly
• Testing
• Aftermarket services
• Cable assembly
• Contract design
• 3-D modeling
• Custom shipment packaging
• Configuration management
• Potting and heat shrink use
• Functional testing
• Encapsulation
• 3-D CAD and physical modeling
• Circuit simulation and optimization
• Costing exercises
• Quality review
• Functional Analysis
• Technical feasibility studies

We are the top china PCB manufacturer from low to mass production. BINGO Technology coordinates the whole process which includes manufacturing, design, assembly, testing and finally shipment. You got a real product according to your design.

BINGO Technology is a China PCB manufacturer and UL certified company. BINGO fabricates 2 to 50 layers PCB which includes rigid, Flex HDI, and Rigid-flex boards. From small to mass production, high quality and low-cost production is our main focus. Moreover, we are manufacturing 400,000 pieces and 30,000 square meters of PCB board manufacturer in china per month. We are one of the top China PCB manufacturers and our professional team mainly focuses on quality control. Our factory has the latest high-level equipment and we bought our core machines from mainstream companies. In short, our quality, management, and core machinery are good as first-class PCB board manufacturer in china.

Volume PCB Manufacturing &

PCB Assembly Projects

Specification

PCB Technical Specification
Order quantity	1-500,000
Number of layer	1,2,4,6,up to 22 layers
Board material	FR-4, glass epoxy, FR4 High Tg, Rohs compliant, Aluminum, Rogers, etc
PCB type	Hard, flexible, rigid-flexible
Shape	Any shape: Rectangular,round,slots,cutouts,complex,irregular, etc
Max PCB dimensions	20inch*20inch or 500mm*500mm
Board thickness	0.4~4.0mm
Thickness tolerance	± 10%
Copper thickness	1/2OZ 1OZ 2OZ 3OZ
Copper thickness tolerance	± 0.25oz
Solder mask	Green, red, white, yellow, blue, black, etc
Silk screen	White, yellow, black, or negative, etc
Silk screen min line width	0.006'' or 0.15mm
Surface finish	HASL, Nickle, Imm Gold, Imm Tin, Imm Silver, OSP etc
Min drill hole diameter	0.01'',0.25mm.or 10 mil
PCB cutting	Shear,V-score,tab-routed
PCB Assembly Capabilities
SMT Jointing Min. Space	0201mm
QFP Space	Pitch 0.3mm
Min. Package	0201
Min. Size	2*2 inch(50*50mm)
Max. Size	14*22 inch(350*550mm)
Placement Precision	±0.01mm
Placement Precision	QFP, SOP, PLCC, BGA
Placement Capability	0805, 0603, 0402, 0201

PCB Lead time (workday(s))
Single, Double-sided	4 layer	6 layer	Over 8 layer	HDI
Sample Lead time (Normal)	5-6	6-7	7-8	10-12	10-12
Sample Lead time (Faster)	48-72 hours	5	6	6-7	12
Mass production lead time	7-9	10-12	13-15	16	20
PCB Assembly Lead time
Sample Lead time	PCB Fab+Components Sourcing+PCBA=15 workdays
Mass production lead time	PCB Fab+Components Sourcing+PCBA=20 workdays

Packing & Delivery

• Inner packing: Anti-static vaccum bag
• Outer packing: High quality carton
