MOQ | 20 MT |
Port | XINGANG,CHINA |
Packaging | LOOSE IN CONTAINER |
Lead Time | WITHIN 10 DAYS |
Radioactivity | NONE | Capacity | 2500MTS every month |
insulated or not | Insulated |
Product Description
Product name:2 core 2.5mm2 flexible control cable wire
Conductor type:flame retardant and oxygen-free copper
material,stranded,2 core
Insulation:environmental,low smoke,halogen free,flame
retardant,anti-aging properties of light pvc/xlpe material
Jacket/Sheathed:pvc
Molding material:plastic
Rated-voltage:300/500v
Applicable temperature:normal working temperature not exceeding
70°
Package:100m/roll,500m/roll,1000m/roll
Application:It can be used in the electrical wire,control cable
and signal transmission line of electric appliance,instrument and
electronic equipment and automatic device, which also can be used
for burglar alarm system,building intercom system and so on.
Additional:any requires will be approved,it's a pleasure to
received it.
Main Item NO. | Insulation Thickness(mm) | Sheath Thickness(mm) | Rmax Of Conductor (20°)(Ω/km) |
2×0.75 | 0.6 | 0.8 | 26 |
2×2.5 | 0.8 | 1 | 7.98 |
2×10 | 1 | 1.2 | 1.83 |
3×1.5 | 0.7 | 0.9 | 13.7 |
3×6 | 0.8 | 1.2 | 3.3 |
4×10 | 1 | 1.4 | 1.83 |
5×2.5 | 0.8 | 1.2 | 7.98 |
6×2.5 | 0.8 | 1.2 | 7.98 |
7×2.5 | 0.8 | 1.2 | 7.98 |
8×2.5 | 0.8 | 1.2 | 7.98 |
10×2.5 | 0.6 | 1.5 | 7.98 |
12×1.0 | 0.6 | 1.2 | 19.5 |
15×1.0 | 0.6 | 1.2 | 19.5 |
41×1.0 | 0.6 | 1.4 | 19.5 |
2×0.75+1×2.0 | 0.4/0.4 | 0.8 | 19.5/9.82 |
5×0.75+1×2.0 | 0.4/0.4 | 1 | 19.5/9.82 |
6×0.75+1×2.0 | 0.4/0.4 | 1 | 19.5/9.82 |
7×0.75+1×2.0 | 0.4/0.4 | 1.2 | 19.5/9.82 |
11×0.75+1×2.0 | 0.4/0.4 | 1.2 | 19.5/9.82 |
12×0.75+1×2.0 | 0.4/0.4 | 1.2 | 19.5/9.82 |
18×0.75+1×2.0 | 0.4/0.4 | 1.2 | 19.5/9.82 |
19×0.75+1×2.0 | 0.4/0.4 | 1.2 | 19.5/9.82 |
24×0.75+1×2.0 | 0.4/0.4 | 1.4 | 19.5/9.82 |
29×0.75+1×2.0 | 0.4/0.4 | 1.4 | 19.5/9.82 |
36×0.75+1×2.0 | 0.4/0.4 | 1.4 | 19.5/9.82 |
38×0.75+1×2.0 | 0.4/0.4 | 1.4 | 19.5/9.82 |
