HY-767L: Fully Automatic Labeling Machine Cylindrical Plastic Ceramic Bottle Chemical Body Care Makeup

HY-767L Fully Automatic Labeling Machine Cylindrical Plastic Ceramic Bottle Chemical Body Care Makeup

Typical Features:

1 color automatic bottle labeling machine

Fast speed up to 4200 bottles per hour

Accurate color to color registration

Suitable for round, oval and square bottles

Mechanical driven bottle transport in high stability

Omron PLC and touch screen controlled

Italy SITI brand main motor

Intelligent UV system saves energy consumption

Integrated anti-static dust blowing and bottle surface flame treating

Main Specifications:

Model NO.:	HY-767L
Round container size:	Diameter: φ10-100mm, Height: 30-260mm
Round container max. print area:	L 260 x W220mm
Oval container size:	R: 10-250mm, Height: 30-260mm
Oval container max. print area:	L 120 x W220mm
Drive:	Mechanical Driven
Control system:	OMRON PLC & Touch Screen
Max. Speed:	70 pcs/min
Registration tolerance:	+/- 0.2 mm
Infeed conveyor:	1 unit, length: 2 meters
Deionizing device:	1 unit
Flame treating system:	1 unit, LP gas
Motor:	ITALY MOTOVARIO

UV system:	1 unit intelligent UV system, 5KW per each
Outfeed conveyor:	1 unit, Length: 2 meters
Frequency Converter:	OMRON
Pneumatic parts:	FESTO or SMC
Electrical:	380V 3phase 50Hz
Air requirement:	5-7 bar
Air consumption:	85 liter/ minute max. (per color)
Power consumption:	5.4 KW/color x 1
Machine size(LxWxH):	Main machine: 2300x1800x1700mm
Weight:	1600 KG
