Product Details

GLASS WASHING MACHINE INTRODUCTION

HISENG glass washing machine for sale consists of an entry area, a washing, drying zone and an exit area. Suitable for different kinds of coated glass washing, special for soft or hard LOW-E glass.

MAIN FEATURES OF GLASS WASHING MACHINE

The HSW washing glass machine features an easy-installing design with an aluminum profile main frame for long life using. It comes standard with PLC control and a touch screen system for simple operation, including automatic glass thickness control and one-key startup. The machine is equipped with a big power blower, upper and bottom brushes, and lifting conveyor motors controlled by inverter, which switches to sleeping mode when no glass is detected, reducing power consumption by up to 65%. All painting parts use powder coating, while water-touching components are stainless steel. The 76mm-diameter rubber rollers ensure durability.

LOADING PART OF GLASS WASHING MACHINE

The loading table rollers are dipped in water for better glass cleaning. A double spray pre-washing system (upper and bottom) features fast-plug nozzles for easy replacement and cleaning. Before entering the washing section, an air cut removes dust from the pre-washing area, preventing contamination. The external water tank has a three-partition design and is mounted on universal wheels for mobility.

WASHING & DRYING SECTION OF GLASS WASHING MACHINE

The upper brushes can be lifted up to 330mm for maintenance. Three pairs of 160mm stainless steel shaft brushes are installed, with two separate lifting cylinders for hard brushes and soft brushes for Low-E and coated glass. Both upper and bottom brushes are inverter-controlled, adjusting rotation speed with washing speed for optimal cleaning. A gear driving system ensures fast and stable rotation, while a high-power blower (inverter-controlled) and two straight air cuts guarantee a thorough drying result.

If you want to know more kinds of vertical glass washer for sale, anything you need, please contact us.
