Genuine humidity and temperature sensor TMAP sensor 5314384 forB 6.7G L8.9G G12 spare part

Name: Genuine humidity and temperature sensor TMAP sensor 5314384 forB 6.7G L8.9G G12 spare part
Brand: Wuhan Yalian Power Technology Co., Ltd.
SKU: Tradewheel_2657309
Price: 70 USD
Availability: InStock

FOB Price 70 - 70 USD / sets

Contact Now

Quick Details (View All)

Condition	New	Warranty	6 Months
Applicable Industries	Manufacturing Plant, Machinery Repair Shops, Construction works	Weight (KG)	0.01
Showroom Location	None	Video outgoing-inspection	Provided
Machinery Test Report	Not Available	Marketing Type	Ordinary Product
Place of Origin	China	Engine Type	Natural Gas
Type	Sensor	Engine Model	Gas engine
Product Name	humidity and temperature sensor	Part number	5314384
Quality	100% Genuine	MOQ	1

Product Details

Installation Instructions

The sensor is designed for attachment to a plane surface on the intake air passage of motor vehicles. The humidity and temperature sensor probe project into the air stream and are sealed to atmosphere by an O-ring. The sensor must be installed in a location that will not subject it to accumulation of condensedmoisture. In order for the sensor to report the true relative humidity of thecombustion air, it must be located an adequate distance upstream of any ports
where other gases are admitted (such as blow-by, exhaust gas recirculation,gaseous fuel).There is a limited range of orientations that are permitted for positioning the
sensor, with respect to horizontal and with respect to the airflow direction. Thepermitted orientations are shown in the figure below. The drawing on the leftshows that the tip of the sensor should point down with an angle from 89° to 40°
(tip of the sensor should never point up). The view is a section of the tube placed at the horizontal position, and the flow axis is into the page. The drawing on the right shows the angle of the sensor compared to the airflow. The airflow should hit the sensor with an angle between 40° and 89°. So the tip should not point in the same direction as the airflow.

Avoid mounting the sensor where it will be subjected to rapid changes in temperature, as these will adversely affect the metrological performance. The mounting boss for the sensor must be designed and manufactured in accordance
with the specifications provided in the customer drawing to ensure proper sealing at the O-ring and avoid undue difficulty or potential damage during installation.
To ensure integrity of the electrical connection to the system harness, the mating connector must be specified and assembled in accordance with the specifications provided in the customer drawing and by the connector
The installation depth in the inlet air tube must be done in such a manner that the sensor openings are located in the air stream.

COMPANY INFORMATION

Wuhan Yalian Power Technology Co.,Ltd

Dear customer, welcome to Wuhan Yalian Power Technology Co.,Ltd, wish you have a nice day!
We specialized in engine field over 15 years, we have professional engineer to help you offer power solution.
We are an experienced engine & all series engine parts supplier and professional engine technology service company.
Main Popular engine are 4BT, 6BT, 6CT,L8.9,L9.5,C8.3,QSB4.5,QSB6.7,etc. Engine Assembly, and engine Spare Parts for after salemarket. Our prices are very competitive.

May I have your email? E-catalog will be sent if you have any interests.

Talk with engine engineer to get help!

PRODUCTS DESCRIPTION

Product name	Humidity and temperature sensor
Product oem no.	5314384
In stock[under 50pc]	yes
Application	engine spare parts
Warranty	6 Months
Delivery	By sea,by air,by express
Package	1. Neutral Packing 2.As customer requirement

PRODUCT SPECIFICATIONS

Why Choose Us

TO LEARN MORE ABOUT US

OUR SERVICE

HIGH QUALITY SERVICE

♦Time is Money -- For all our clients, you will receive efficient service and exactly what you ordered, and you will receive it on
time

♦If you need sample ,we can provide it for free ,You only need to bear the shipping cost of the product yourself

♦Super Value -- We have much cost advantage. By choosing us, you can increase profit and gain more market.

Get better price !

Recommend Products

Packaging And Shipping

Strong packing to protect goods well:

1. Inner Package :Each piece with anti rust oil and plastic bag.
2. Outer Package : 1Pcs / wooden case. And then use the wooden pallets.
3. Brand packing or neutral packing or customized packing,according to your demands!
4. We are prepared to accept orders for goods with customers’ own trade marks or brand names.
5. According to your requests, we provide ship by sea ,by air or land transportation.
We have some long-term cooperated forwarders. So dont worry, we can help you to handle everything.

FAQ

List some questions below we think you may want to know, if you have more doubts, we are right here to help you.

Q.Whats your payment?
A: We accept T/T, L/C, trade assurance also acceptable.

Q: What is your terms of payment ?
A: Payment=1000USD, 30% T/T in advance ,balance before shippment.

Q:Whats your warranty?
A: Any quality problem found when the goods arrive, please contact us,if it is really our duty, we will resend you the same parts
with the next batch order freely.
We do hope long term cooperation with you. Thinking deeply, we need to help you win a good reputation among the consumers, in
quality, delivery speed, package etc. The more you sell, the more you will buy from us.

Q. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery

Q: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.

Q:Whats your MOQ?
A: Please refer to the minimum order standards on the page or consult us directly
