Excellent heat transfer white highly thermal conductive epoxy AB glue two-component epoxy adhesive

Name: Excellent heat transfer white highly thermal conductive epoxy AB glue two-component epoxy adhesive
Brand: Xiamen Aibeisen Electronics Ltd
SKU: Tradewheel_2659730
Price: 4 USD
Availability: InStock

FOB Price 4 - 8 USD / pieces

Contact Now

Quick Details (View All)

CAS No.	mixture	Other Names	Two-component epoxy adhesive
Place of Origin	Fujian, China	Classification	Double Components Adhesives
Main Raw Material	Epoxy resin	Usage	Electronics
Brand Name	APS	Model Number	EP-720
Type	adhesive	Color	White

Product Details

Adhesive bonding type epoxy AB glue

INTRODUCTION

EP-720 is a high performace thermal conductive adhesive and has excellent moisture resistance, heat resistance and excellent bonding properties.

It is widely applied in the areas which require bonding and thermal conductivity, such as LEDs, semiconductors and other electronic components that require heat transfer

Specification

Testing Item	Testing Method or Condition	EP231220A	EP231220B
Appearance	Visual	white	white
Viscosity	25 0C Pa*s	60000±20000	20000±30000
Specific gravity	g/cm3	1.05	1.05
Expiration date	Room temperature ventilated	6months	6months

Item	Unit or Condition	EP-720A/B
Mixing Ratio	Weigh Ratio	A:B=2:1
Mixed viscosity	25 0C Pa*s,	100-120
Up Time	200g, 25 0C/h	1
Curing conditions	0C/hrs	48 hours @ 25 ℃ or 1hours@ 80 ℃

CURED PROPERTIES

Item	Unit or Condition	EP-720A/B
Hardness	25 0C, Shore-D	82±5
Volume resistivity	25 0C, Ω·cm	≥1.0*1013
Surface resistivity	25 0C, Ω	>1014
Insulation intensity	25 0C, kV/mm	>22
Dielectric constant	25 0C,1MHZ	4.2±0.1
Compression strength	kg/mm2	>25
Bending strength	kg/mm2	>10
Impact strength	kg/mm2/cm2	>6
Shear strength (Al/Al)	kg /cm2	≥80
Shear strength (Al/PVC)	kg /cm2	Material broken

STORAGE

1. It should be storeed in light-protected,sealed, dry place.

2.This product doesnt belong to dangerous goods; it can be stored and transported as usual goods.

3. Please clean the parts which wants to bonding first to get the best adhesion.

4. Out of the reach of children.

5. Avoid direct contact with skin and eyes, especially the component B, in case of contact with eyes, please clean with water, and go to hospital immediately.

Company Information

Xiamen Aibeisen Electronics Co., Ltd. was established in 2005. It is a National High-tech Enterprise specializing in the research, development, production, sales, and technical services of electronic industrial adhesives, thermal interface materials, and electronic soldering materials.

Advantages

The company collaborates with both the Institute of Chemistry, Chinese Academy of Sciences and the College of Materials Science and Engineering, Xiamen University, jointly establishing an industry-academia-research platform. It also recruits Ph.D. and graduate students from the two research institutes as key technical personnel for the R&D team. With nearly 18 years of development, the company boasts a highly skilled and experienced R&D team, focusing on the research, development, and production of electronic industrial adhesives, thermal interface materials, and soldering materials. It provides customers with solutions, including product development, simulation testing, and adhesive application processes.

Honors & Certifications

The company has earned the title of a "National High-tech Enterprise" and holds multiple invention patents. It has obtained IATF16949, ISO14001, and ISO9001 system certifications, and some of its products have passed UL and SGS testing certifications as well. Additionally, the company is equipped with advanced production equipment and professional testing instruments. With rigorous and scientific management, the company ensures that its products meet customers quality and technical requirements.

Our Partners Currently, Aibeisen has become a well-known brand both in China and internationally. Aibeisen supplies high-quality products to affiliated companies such as Microsoft, Amazon, Huawei, OPPO, Xiaomi, VIVO, Ford, FLYPRO, Tianma Microelectronics, and CATL. The products find wide-ranging applications in mobile communication, chip packaging, display modules, touch modules, camera modules, motors, fingerprint recognition, automotive applications, and new energy facilities. Management Philosophy Aibeisen consistently adheres to the management philosophies of "Dedication, Innovation, and Quality" and implements a continuous improvement process from research and development to production and technical services. Aibeisen is committed to growing alongside our customers to create a bright future together.

FAQ

1:Are you trade company or manufacturer?
We are an China professional manufacturer of customized various thermal interface materials,such as silicone insulation conductive
pad,thermal conductive tape,thermals conductive graphite etc with more than 15years experience in this line.

2:How can you guarantee the quality?
With advanced production machine and testing equipment,we ensure 100% quality inspection before shipping.

3:Whats the leading time?
Sample order costs 5-7 workdays and 7-10 working days for mass production.

4:Can I take sample?
We are honored to provide you sample for testing.

5:What payment term is available?
We can accept L/C,TT,Paypal.West Union.

Related silicone insulation conductive pad you may interest ,pls feel free to contact with me .
