MOQ | 1 Set/Sets |
Place of Origin | China | Model Number | ZSPJ |
Technics | Forged | Connection | Female |
Head Code | Hexagon | Model | ZSPJ-15 |
Material | stainless steel | Size | 1/2" |
Color | Silver | packing | Carton |
used for | sprinkler / Pipe | Adjustable angle | 68° |
Model zspj
Material: stainless steel, copper alloy
1. Product overview
The product is used to connect the water supply pipe and the spray nozzle, so as to adjust the spray angle and cover all the protective objects.
2. Advantages
When the spray angle is locked in any direction of its adjustment angle, even when the spray is applied by a large flow high-speed centrifugal spray nozzle with 400 l / min, it will not loosen or shift due to the reaction force.
3. Main performance parameters
1) Rated working pressure: 1.2MPa
2) Water inlet interface: R1 / 2, R3 / 4, R1; outlet: RC1 / 2, RC3 / 4, RC1.
3) Material: stainless steel, copper alloy.
4) Seal: with the grinding of spherical surface, the hard seal will not leak or loosen at any adjustment angle
Model | Water inlet interface | Water outlet connector |
Material |
ZSPJ-15 | R1/2 | Rc1/2 | Stainless steel, copper alloy |
Model |
inlet |
outlet |
A(mm) |
B(mm) |
angle |
ZSPJ15 |
R1/2" |
R1/2" |
75.6 |
60 |
68° |
ZSPJ20 |
R3/4" |
R3/4" |
80 |
60 |
50° |
ZSPJ20/15 |
R3/4" |
R1/2" |
78 |
60 |
68° |
