PVC Electrical Tape for Insulating RoHS2.0 Factory High Temperature

Quantity	20,000 - 99,999	100,000 - 299,999	300,000+ - 300,000+
Price	US $0.19	US $0.18	US $0.17

Contact Now

Quick Details (View All)

Base Material	PVC	Type	Pressure-Sensitive Tape
Standard	En60454-3-1	Min.Length	3m
OEM Order	Acceptable	Voltage	600V
Transport Package	Carton, Pallet	Specification	0.15mmx19mmx20m
Trademark	SHUSHI	Origin	China
HS Code	3919909000	Production Capacity	8000 Cartons Per Day

Product Details

Product Description

Company Info.

Product Description

Factory High Temperature PVC Electrical tape for Insulating RoHS2.0

Electrical Tape RoHS compliant

The tape is based on quality plasticized poly vinyl chloride film coated with high performance rubber based pressure sensitive adhesive; its resistant to most of chemicals and moisture. This Electrical tape is conforms to RoHS requirements and prevents the incremental damage caused by toxic heavy metal content such as lead, cadmium etc as in other general electrical tape to guarantee the safety of user. No DOP plasticizer used.

Characteristics

Flexible

Good elasticity

Flame Retardant

Eco-friendly, RoHS approved

healthy and safe

Ageing Resistant

Excellent adhesion and electrical insulation properties

Application

Electrical repair

Colour coding and insulation of electrical cabling

Protection for sheath of high & low voltage wire and cable

Other occasions that fire prevention is strictly required

Specification

Various Length:10m 15m 20m 30m

Various Width:18mm 19mm

Inner Core Diameter:32mm 38mm

Colors:Black White Blue Green Red Yellow

Part No.

R130Z R150Z R170Z

Technical parameters

PROPERTY	UNIT	R130Z	R150Z	R170Z	TEST METHOD
Thickness	mm	0.13	0.15	0.17	ASTM D 1000
Tensile Strength	N/cm	20	22	24	ASTM D 1000
Elongation	%	160	170	180	ASTM D 1000
Electrical Strength	kV/mm	40	40	40	ASTM D 1000
Peel Adhesion (180o)	N/cm	1.8	1.7	1.6	ASTM D 1000
Flame Test	--	Pass	Pass	Pass	UL510
Content of RoHS Restricted Substances
Cadmium	ppm	<100	<100	<100	IEC62321
Lead, Mercury, Chromium(VI)	ppm	each<1000	each<1000	each<1000	IEC62321
PBBs,PBDEs	ppm	each<1000	each<1000	each<1000	IEC62321
DEHP, BBP, DBP, DIBP	ppm	each<1000	each<1000	each<1000	IEC62321
