Quantity | 1 - 9 | 10 - 49 | 50 - 100 | 200 - 499 | 500 - 1000 |
Price | 1600USD | 1570USD | 1520USD | 1480USD | 1400USD |
Port | Shanghai Port |
Packaging | Packed by carton, one piece a carton |
Lead Time | 50 days |
Input Voltage | 85-265V AC | Output Voltage | 200-420V DC |
Input Current | 32A | IP rate | IP67 |
Cooling | Liquid-cooled | Efficiency | 94% |
Weight | 14kg |
OBC input | |
Input Voltage | 85-265VAC |
Input Current | 32A |
Input Frequency | 45-65Hz |
DC-DC converter input | |
Input Voltage | 200-420VDC |
Input Current | 7A |
OBC output | |
Output Voltage | 200-420VDC |
Output Current | 20A max |
LV Output | 14VDC 7A |
Output Power | 6.6KW max |
Output Current Accuracy | ±0.4A |
Output Ripple & Noise | ±2%mVp-p |
Output Wakeup Voltage | 12VDC |
Output Wakeup Current | 200mA |
Efficiency | 95% |
DC DC converter output | |
Output Voltage | 9-16VDC |
Rated Output Voltage | 14VDC |
Output Current | 108A |
Output Power | 1.5KW |
Maximum Output Power | 1.8KW |
Output Voltage Accuracy | ±1%Vo |
Output Ripple & Noise | 300mVp-p |
Efficiency | 94% |
Technical Parameters | |
Communication | CANbus |
Baud Rate | 250K/500K |
Operating Temperature | -40 to 85℃ |
Altitude | 5000m |
IP rate | IP67 |
Cooling | Liquid-cooled |
Dimension (LxWxH) | 443x326x91mm |
Net Weight | 10kg |
Protections |
input&output under voltage protection input&output over voltage protection over temperature protection output short circuit protection |
