HEPA PPS Fabric Filter Cloth for Air Filtration

Name: HEPA PPS Fabric Filter Cloth for Air Filtration
Brand: Shanghai Sffiltech Co., Ltd.
SKU: Tradewheel_2471089
Price: 1.35 USD
Availability: InStock

FOB Price 1.35 - 1.5 USD / pieces

Contact Now

Quick Details (View All)

Model NO.	019	Hole Shape	Acupuncture
Manufacturing Method	Manufacturing Cloth	Paper Type	Qualitative
Weight(G/M2	500GSM	Temperature(u00baC)	Continue190, Instant230
Air Permeability	200~300	Transport Package	Carton or Wooden Case
Specification	Regular size; Customizable	Trademark	SFFILTECH
Origin	Shanghai; China	Production Capacity	50000square Meters

Product Details

Product Description

Product Description

Material		PPS needle felt
Weight(g/m2)		500
Tensile Strength (N/5×20cm)	Warp	1250
	Weft	1350
Tensile elongation(%)	Warp	≤30
	Weft	≤30
Temperature(ºC)	Continue	190
	Instant	230
Thickness(mm)		1.8
Air permeability(L/m²/s)		200~300
Finishing treatment		Heating,Singeing,Calendering

Material:
PPS needle punched felt
450gsm, 500gsm, 550gsm
Finish Treatment:
Singed, calendered, heat set, water&oil repellent, PTFE membrane

Size: diameter 100mm, 125mm, 130mm, 150mm, 180mm, 250mm ect.
Any length is available. Special size is customize.

Process Method: sewing or welded

Advantages:
High temperature resistant
Working temperature:190 degree
Max temperature: 230 degree
No melting point, yellow color
PPS has large filtration area and excellent filtration performance.

Dust collector filter bag:
Since every filter has its own characteristics and parameters,
when we chose filter material for dust collector filter bags,
we have to know the following parameters: temperature, humid,
dust diameter, gas chemical properties, dust abrasive, filters mechanical parameters.
Generally, SFF dust collector filter bags are widely used in industrial waste gas filtration, useful dust, high temperature gas filters.
Shanghai filter bag factory provides you good solution according to dust characteristics, help you chose good filter material to achieve best filtering effective.
