| Port | Ningbo |
| Product name | lc Duplex connector uniboot patch cord | Connector type | FC SC ST LC |
| Cable length | 1m 2m 3m 5m 10m and so on | Certification | ISO9001 CE ROHS |
| Insertion loss | ≤ 0.2dB | Material | PVC ,CORNING FIBER, LSZH,G652D,G657A1 |
| Type | Simplex and Duplex | Operating Temperature | -40~85°C |
| Return Loss | ≥ 50dB |
Eonkey FTTH assemblies jumper cable fiber optic Duplex OM3 2m 2.0 3.0mm lc connector uniboot patch cord
|
Technology Data |
|
|
Name |
lc Duplex connector uniboot patch cord |
|
Part No. |
EK01D |
|
Connector type |
LC SC ST FC |
|
insertion loss |
≤ 0.2dB |
|
color |
Blue,Green,Grey,purple,aqua |
|
Type |
Simplex, Duplex |
|
Material |
PVC ,CORNING FIBER, LSZH |
|
Operating Temperature |
-40~85°C |
|
Application |
FTTH FTTB FTTX Network |
Optical Specification:
|
Connector |
SC,FC,LC,ST,MU,E2000,MTRJ |
MPO/MTP |
|||
|
Polishing |
SM/UPC |
MM/PC |
SM/APC |
SM/PC |
MM/PC |
|
insertion Loss(max) |
≤0.30dB |
≤0.30dB |
≤0.30dB |
≤0.75dB |
≤0.5dB |
|
Return Loss(min) |
≥50 dB |
≥35 dB |
≥60 dB |
≥40dB |
≥20dB |
|
Tensile Strength |
<10kg |
||||
|
Durability |
<0.20 dB typical change, 500 matings |
||||
|
Repeatability |
≤0.1dB |
||||
|
Storage , Operating Temperature [°C] |
-40~+85 |
||||
Features and Benefits:
Low insertion loss.
High return loss.
Precise endface inspection by microscope.
Environmentally stable to electricat interference
Optical fiber communication network, data transmission, test instruments, LAN,Cable CATV.
Packing of lc Duplex
connector uniboot patch cord:
1m patch cord:75pcs in an inner box,4pcs inner box in an out
carton(450*450*250).
2m patch cord:50pcs in an inner box,4pcs inner box in an out carton(450*450*250).
3m patch cord:50pcs in an inner box,4pcs inner box in an out carton(450*450*250).
5m patch cord:40pcs in an inner box,4pcs inner box in an out carton(450*450*250).
10m patch cord:40pcs in an inner box,4pcs inner box in an out carton(450*450*250).
12m patch cord:25pcs in an inner box,4pcs inner box in an out carton(450*450*250).
15m patch cord:20pcs in an inner box,4pcs inner box in an out carton(450*450*250).
20m patch cord:15pcs in an inner box,4pcs inner box in an out carton(450*450*250).
25m patch cord:20pcs in an inner box,4pcs inner box in an out carton(450*450*250).
30m patch cord:8pcs in an inner box,4pcs inner box in an out carton(450*450*250).
40m patch cord:8pcs in an inner box,4pcs inner box in an out carton(450*450*250).
50m patch cord:6pcs in an inner box,4pcs inner box in an out carton(450*450*250).
Delivery of lc Duplex connector uniboot patch cord: 3-7 days after payment
The best service for you
1,Do you provide free lc Duplex connector uniboot patch cord samples?
------ yes, we can supply some free samples , the buyer should bear the shipping cost.
2,Are you trading company or manufacturer ?
------ We are factory also trader.
Welcome to visit us in any time.My cell number is +86 *********
3,How long is your delivery time?
------ Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
4,What is your terms of lc Duplex connector uniboot patch cord?
------ Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
