MOQ | 5 UNIT |
Port | Shanghai |
Packaging | Carton |
Lead Time | 3~7 day after payment |
BD300 Optical Time Domain Reflectometer has excellent dead zone performance and wide dynamic range. Combined with the visual fault locator, the OTDR can easily find the breaks, bends, splices, faulty connectors, and other causes of signal loss.
Learned from the operation mode of tablet computer and smart mobile phone, BD300 series OTDR has simple operation interface and Windows-like GUI, and this ensures a short learn curve for the customer.It is small, lightweight, portable, rugged and durable, and is more suitable for outdoor environment
Key Features
u Optimized measurement
l For network opening: high speed test mode
l For network maintenance: accurate test mode
u Multiple combinations of different dynamic ranges and wavelengths are available
u Support real-time measurement mode and average measurement mode
u Support line light alarm function and maximize the protection of the optical device
u The optical module has self-test function, and can automatically detect its performance and state
u Support Chinese and English input. Have friendly input interface and mobilephone-like input style
u USB interface can easily transfer data between the device and the PC
u Portable, hand-held and high cost-effective
Related Video:
How to operate BAUDCOM mini OTDR?
Applications
ü The installation and maintenance for AN(access network) optical cables
ü The installation and maintenance for LAN(local area networks)
ü The installation and maintenance for FTTX
ü The installation and maintenance for cable TV networks
ü The installation and maintenance for APON(optical networks)
ü The installation and maintenance for private optical fiber networksn Specifications
Model |
BD300 |
Wavelength |
1310nm or 1550nm |
Type of fiber |
9/125um SM Fiber |
Connector |
FC、SC/PC |
Dynamic Range |
22dB |
Pulse Width |
10ns~ 2.5us,Auto |
Measurement |
m |
Event blind zone |
3m |
Attenuation blind |
10m |
Range accuracy |
±(1m+2×10-4×distance) |
VFL |
≥1mW |
Power Supply |
3pcs of Dry battery |
Battery Work time |
≥2000 times measure |
Save Data |
>500 |
Work Temperature |
-5~40℃ |
Save Temperature |
-10~60℃ |
humidity |
0~85%(no condensation) |
Net weight |
300g |
