Product Details
1. Product Overview & System Architecture
The
AliBarBar Upload 25000 Puffs is a
high-capacity, modular e-cigarette system comprising two distinct
components: a detachable, reusable control host equipped with a
smart HD screen and integrated battery, and a high-volume
pre-filled replacement pod. The architecture utilizes a magnetic
interface to secure the pod to the hardware host. Once the liquid
inside the pre-filled pod is fully atomized, the consumer retains
the electronic host and replaces only the dedicated 25000-puff
tank cartridge. This system functions as a hybrid between a
high-capacity disposable and an advanced closed pod kit.
2. Technical Specifications Table
|
Feature / Metric
|
Specification Details
|
|
System Classification
|
Modular Closed Pod Kit / Reusable Smart Hardware
Host
|
|
Maximum Rated Output
|
Up to 25,000 Puffs (Subject to user inhalation
duration)
|
|
Atomizer Structure
|
Dual Mesh Coil Integration (Alternating firing
system)
|
|
Coil Resistance
|
Dual 1.0 Ω (Ohm)
|
|
Vaping Profiles
|
Regular Mode (Balanced flavor) / Boost Mode (Increased
cloud volume)
|
|
Power Output Adjustment
|
Automatic via mode toggling
|
|
Battery Type
|
High-density Lithium-ion internal cell
|
|
Battery Capacity
|
800 mAh
|
|
Charging Interface
|
USB Type-C
|
|
Charging Protocol
|
5V / 1A (Fast charging supported)
|
|
User Interface Display
|
High-Definition Color Screen
|
|
Real-time Indicators
|
E-liquid Level %, Remaining Battery Life %, Mode
Indicator
|
|
Hardware Coupler
|
Dual Magnetic Retention Pins + Mechanical Alignment
Channel
|
3. Atomization Core Configuration
-
Dual Mesh Alternating Firing System: The internal
chamber contains two distinct 1.0Ω mesh heating elements. The
device switches between coils during inhalation to reduce heat
degradation, minimize coil buildup, and maintain uniform flavor
profile accuracy throughout the lifecycle of the 25,000-puff
reservoir.
-
Dual Mode Output Control: Users can switch between
Regular Mode (standard vapor output, higher puff count
efficiency) and Boost Mode (simultaneous dual-coil firing,
lower air resistance, higher vapor volume output).
4. Power Management & Charging Specifications
-
Reusable Battery Module: Unlike standard single-use
vapes, the 800mAh battery block is designed to endure hundreds
of recharge cycles, acting as a permanent hardware anchor for
the replacement pod line.
-
Type-C USB Protocol: Standardized bottom-mounted Type-C
port accommodates universal 5V charging inputs, protecting the
lithium-ion cell from overheating and voltage spikes during
recharging.
5. Regulatory Compliance & Parameters
-
Hardware Certification: The core electronics host,
circuit board, and battery assembly carry official
CE, RoHS, and FCC compliance marks.
-
Safety Cut-offs: Built-in electronic protection includes
Over-inhale Protection (10-second cutoff), Short-Circuit
Protection, Low-Voltage Protection, and Overcharge
Protection.
-
Market-Specific Nicotine Options: Available in
0% (Nicotine-Free) for strict European market
compliance, as well as 2% and 5% salt nicotine strengths
intended for compliant jurisdictions outside of the European
Union.
6. Structural & Manufacturing Advantages
-
E-Waste Reduction Design: Isolating the lithium-ion cell
and the PCB/LED screen assembly into a permanent housing
reduces single-use plastic and heavy metal disposal by up to
70% compared to traditional single-use 25000-puff
hardware.
-
Leak-Proof Multi-Layer Tank Isolation: The replacement
cartridge employs a multi-tiered silicone gasket array and an
isolated air channel path to prevent liquid migration into the
magnetic connection bay or onto the internal circuit
paths.
7. B2B OEM & ODM Customization Options
We provide comprehensive original equipment manufacturer (OEM)
and original design manufacturer (ODM) services for bulk order
accounts:
-
Flavor Development: Access to an existing library of
over 30 tested flavor formulations, with custom lab-mixing
options to match local market profiles.
-
Nicotine Graduation: Precision blending available for
0mg/ml, 20mg/ml, 30mg/ml, and 50mg/ml strengths.
-
Private Labeling & Graphics: Custom silkscreen printing
on the modular housing, customized UI start-up screens, and
full compliance-ready exterior packaging design.
8. Frequently Asked Questions (FAQ)
-
Q: Must the buyer discard the entire device when the liquid is
empty?
-
A: No. The buyer retains the smart screen hardware
host. Only the empty pre-filled 25,000-puff pod cartridge
is disposed of and replaced.
-
Q: Does the 25000 puff capacity comply with European Union
customs?
-
A: For the EU market, this system is primarily
imported as a
0% Nicotine (Nicotine-Free) device, which legally
bypasses the 2ml liquid tank capacity limits set by the TPD
framework for nicotine products.
-
Q: What is the packaging standard for wholesale bulk
shipments?
-
A: Hardware modules and pod components are sealed in
individual anti-static foil bags, organized into inner
counter boxes, and shipped inside heavy-duty, double-walled
export cartons reinforced for long-distance
logistics.
