| Quantity | 1 - |
| Price |
| MOQ | 1 set |
| Port | Shanghai,Beijing,Shenzhen,Hongkong |
| Packaging | 1 set per box |
| Lead Time | 2-5 working days |
Application
Single hook electric cable hoist ,monorails, double speed electric hoist or electric double speed hoist crane,floating crane ,overhead crane ,vehicles equipment ,door control system ,engineering machinery ,lifting platform ,traveling crane ,hydraulic equipment and used for industrial remote control which are under 11 control points
Feature:
1.
10
function double speed button + 1 Start + 1 Emergency Stop + 1
on/off Switch
2.
With Battery voltage warning device, the power supply is cut off
during low power
3.Program
the button function by computer software
4.Safty
key prevents from unauthorized user.
5.Up/down
can be programmed to interlock or non-interlock,toggle and normal
etc.
6.
Start button can be program to be start, Normal, toggle function
etc.
Basic Data:
|
TX Model |
F24-10S-TX-V-(E) |
|
TX Size |
about 18.8x6.4x4.8(cm) |
|
TX Weight |
about 293g(without Batteries) |
|
Housing Materail |
glass fiber-reinforced nylon-6 |
|
Protection Degree |
IP65 |
|
Temperature Rating |
-35°C ~ +85°C(Regardless of the battery temperature tolerance) |
|
TX power Supply |
Two 1.5 volts Batteries(AA Size) |
|
Number of buttons |
10 Double speed buttons,1 START button, 1 mushroom button,1Rotary switch |
|
Button Marking |
arrow tip |
|
I.D.Code |
4.3 billion |
|
Voltage Warning |
TX Red LED will flash slowly when the volts under 2.2V,and unable to start TX under 1.8V. |
|
Operating Frequency |
310.0325-331.165MHz |
|
Channel Spacing |
0.2675MHz |
|
Channel |
80CH |
|
RF Power |
<10DBm |
|
Fault Detection |
TX Red
LED is flashing quickly: |
