0.6/1kV Unarmored Copper Power Cable

Product Details

Product Description

Application

The cable are mainly used for power distribution in power stations, industrial installation and switchgears, as well as in local mains. Able to bear certain traction during installation. For fixed installation underground, in interior premises, cable ducts, in the open air and in water if no risk of any mechanical damage is to be expected. Laying single core cable in magnetic ducts is not allowed.

Characteristics

Rated voltage: 0.6 / 1 kV

Maximum Conductor Temperature: under normal (90℃), emergency (130℃) or short circuit no more than 5s (250℃) conditions.

Min. Ambient Temp. 0℃, after installation and only when cable is in a fixed position

Min. Bending Radius: 20 x cable O.D for single core

15 x cable O.D for multi core

Standards

International: IEC 60502, IEC 60228

China: GB/T 12706

Other standards such as BS, DIN and ICEA upon request

Certificates

CE, RoHS, CCC and more others at request
