| Place of Origin | Anhui, China | Model Number | Sun Series |
| Brand Name | Deye | Input Voltage | 48V |
| Output Voltage | 100-240V / 380-415V | Output Current | 10-100A |
| Output Frequency | 50/60Hz | Output Type | Single, DUAL, Three Phase |
| Size | 464W*798.4H*300D | Type | DC/DC Converters, DC/AC Inverters |
| Inverter Efficiency | 98% | Weight | 48kg |
| PV Input Power | 1000-20000W | MPPT Voltage Range | 150-500V |
| Battery Type | Sealed/FLood/GEL/LFP/Ternary | Battery Voltage | 24V/48V DC |
| Output Voltage Waveform | Pure Sine Wave | Working Temperature Range | -45~60u2103 |
| Noise (dB) | <30 dB | Communication with BMS | RS485; CAN |
| Protection Degree | IP65 | Warranty | 5 years, 10 Years |
| Certificate | CE/IEC |
|
Model
|
SUN-8K-SG04LP3
|
SUN-10K-SG04LP3
|
SUN-12K-SG04LP3
|
|||
|
Battery Input Data
|
||||||
|
Battery Type
|
Lead-acid or Li-lon
|
|||||
|
Battery Voltage Range (V)
|
40~60V
|
|||||
|
Max. Charging Current (A)
|
190A
|
210A
|
240A
|
|||
|
Max. Discharging Current (A)
|
190A
|
210A
|
240A
|
|||
|
Charging Curve
|
3 Stages / Equalization
|
|||||
|
External Temperature Sensor
|
Optional
|
|||||
|
Charging Strategy for Li-Ion Battery
|
Self-adaption to BMS
|
|||||
|
PV String Input Data
|
||||||
|
Max. DC Input Power (W)
|
10400W
|
13000W
|
15600W
|
|||
|
PV Input Voltage (V)
|
550V (150V~800V)
|
|||||
|
MPPT Range (V)
|
200V-650V
|
|||||
|
Start-up Voltage (V)
|
160V
|
|||||
|
PV Input Current (A)
|
13A+13A
|
26A+13A
|
26A+13A
|
|||
|
No.of MPPT Trackers
|
2
|
|||||
|
No.of Strings Per MPPT Tracker
|
1+1
|
2+1
|
2+1
|
|||
|
AC Output Data
|
||||||
|
Rated AC Output and UPS Power (W)
|
8000W
|
10000W
|
12000W
|
|||
|
Max. AC Output Power (W)
|
8800W
|
11000W
|
12000W
|
|||
|
Peak Power (off grid)
|
2 times of rated power, 10 S
|
|||||
|
AC Output Rated Current (A)
|
12A
|
15A
|
18A
|
|||
|
Max. AC Current (A)
|
18A
|
23A
|
27A
|
|||
|
Max. Continuous AC Passthrough (A)
|
50A
|
|||||
|
Output Frequency and Voltage
|
50/60Hz; 230/400Vac (Three phase)
|
|||||
|
Grid Type
|
Current Harmonic Distortion
|
|||||
|
Current Harmonic Distortion
|
THD
|
|||||
