| Grade | Industrial | Warranty | 12 months |
| Customized support | OEM, ODM, OBM | Place of Origin | Shaanxi, China |
| Brand Name | Moray | Model Number | ME421WSP |
| Material | Stainless Steel 304 /316L / TC4 (optional) | Mode | Submersible level sensor |
| Range | 0~1...200m H2O | Output signal | 4~20mA 0~5V 1~5V 0.5~4.5V 0~10V RS485 |
| Power source | 5V,12~30VDC | Accuracy | 0.5%FS/0.25%FS, 0.1%FS (optional) |
| Operating temperature | -10~80u2103 | Cable | PE/ PU/ FEP |
| Media type | Air/Water/Refrigerate liquid | Application | Overload Pressure 150%FS |
| Applicable Industrial | Directly Cable IP68 | Keywords | Submersible Water Level Sensor |
|
Level Range
|
0~1m...200mH20
|
|
Pressure type
|
Gauge
|
|
Output signal
|
4~20mA,0~5V,1~5V,0.5~4.5V,0~10V,RS485
|
|
Power supply
|
5V,10~30VDC
|
|
Compensated temperature range
|
-10~70℃
|
|
Operating temperature range
|
-10~80℃
|
|
Storage temperature range
|
-40~125℃
|
|
Over pressure
|
150%FS
|
|
Response time
|
≤100mS(from power on to data stable)
|
|
Load resistance
|
